Ultrasonic Flow Meters measures FLOW RATES of a find using ultrasonic technology.

Ultrasonic Flow Meter


It is a handhold tansit-time ultrasonic flow meter with clamp-on, transducers for non-invasive liquid measurement. Our microprocessor based, user friendly and field programmable flow measurement technique allows no interruption of the process flow and has low installation costs.


  • 4-line LCD display with flow rate; totalized and signal condition
  • The flowmeter is designed for high accuracy of +/-1.0%
  • Small size (200*92*32mm); light-weight(538g)
  • Wide range; velocities(0.01-+/-32 m/s)
  • Ni-MH battery life for upto 10 hours continuous operation.
  • Transducers for pipe sizes of 13 to 6000 mm
  • Transducers include the magnetic devices which can install on metal pipe without mounting belt.
  • Date logger which records flow rate, date, total flow, signal condition, etc.
  • Response Time: less than 1 second.

Technical Specification:

Measuring Principle Transit time difference
Pipe Size SS Type: 15mm~100mm( 1/2"~4") M Type: 500mm~700mm(2"~28") L Type: 300mm~600mm(12"~240")
Resolution 0.0001 m/s
Pipe Material Cast Iron, Stainless Steel, Ductile Iron, Copper, PVC, Aluminium, Asbestos, Fiberglass
keypad 18 keys with tactile action
Response time less tahn 1 second
Ambient Temperature 90% RH or less
Built in battery Ni-MH battery
Operation Time > 10 hours
Line Material Tar Epoxy, Rubber, Mortar, Polypropylene, Polystyrol, Polystrene,Polyester,Ebonite,Ployethylene, Teflon etc.
Display 4 Line LCD with illumination
Flow Rate 5 digits with decimal point
Totalize 8 digit, Forward, Reverse & Net values
Engineer Unit M3, Liter, US Gallon, Imperial Gallon, Million Gallon, Cubic Feet, US Barrels, Imperial Barrels, Oil Barrel
Time Unit Second, Minute, Hour, Day
Other Velocity, Date, Time, Signal Condition
Accuracy +/-1%~+/-2% of reading (0.5~30 m/s)+/-0.5% reading (online calibration)
Repeatability +/-0.2% of reading
Charger 90~260VAC 50/60Hz, 8-12 Hr charging
Data Storage Operation parameters and totalization data are stored by EEPRPM for more tahn 10 years
Data Logger 64 data include flow rate, totalizer, time, date
Alarm High/Low with buzzer
Power consumption less tahn 2W
Dimension 200*92*32
Weight 054 KG
Enclosure Converter: IP65 Sensors:IP68 (Submersible)
